Nginx To APISIX: Configuration & Plugin Guide

by Sebastian Müller 46 views

Hey guys! Ever found yourself needing to migrate your Nginx configurations to Apache APISIX? It can seem daunting, especially when dealing with complex proxy setups. But don't worry, we're here to break it down and make it super easy for you. In this guide, we'll walk through how to configure Nginx proxy settings within APISIX, or alternatively, how to achieve the same results using APISIX plugins. Let's dive in!

Understanding the Nginx Configuration

Before we jump into APISIX, let’s first understand the Nginx configuration we’re aiming to replicate. The Nginx configuration snippet provided is a classic example of setting up a reverse proxy. Let's quickly break down what each line does:

server {
 listen 8080;
 server_name localhost;

 location /attu/ {
 proxy_pass http://localhost:3000/;
 proxy_http_version 1.1;
 proxy_set_header Upgrade $http_upgrade;
 proxy_set_header Connection "Upgrade";
 proxy_set_header Host $host;
 proxy_set_header X-Real-IP $remote_addr;
 proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
 proxy_set_header X-Forwarded-Proto $scheme;
 }

}
  • listen 8080;: This tells Nginx to listen for incoming connections on port 8080.
  • server_name localhost;: This specifies that this configuration applies to requests coming to localhost.
  • location /attu/ { ... }: This block defines how to handle requests that start with the /attu/ path.
  • proxy_pass http://localhost:3000/;: This is the core of the reverse proxy. It forwards requests to the upstream server running on http://localhost:3000/.
  • proxy_http_version 1.1;: This sets the HTTP version for the proxy connection to 1.1, which is necessary for features like keep-alive connections.
  • proxy_set_header directives: These lines set various HTTP headers that are passed to the upstream server. These headers provide crucial information about the original request, such as the client's IP address, the original host, and the protocol used.
  • Upgrade $http_upgrade: This header is essential for WebSocket connections. It checks if the client requests an upgrade (e.g., to WebSocket). If it does, the header’s value is set to the upgrade type, facilitating the upgrade process.
  • Connection "Upgrade": This header works in conjunction with the Upgrade header to ensure the connection is upgraded as requested. It signals to both the proxy and the upstream server that a connection upgrade is desired.
  • Host $host: This header forwards the original host requested by the client, allowing the upstream server to handle virtual hosts or serve content based on the host.
  • X-Real-IP $remote_addr: This header passes the real IP address of the client to the upstream server. This is crucial for logging and security purposes, as it allows the upstream server to know the actual source of the request, especially when the proxy sits behind other proxies or load balancers.
  • X-Forwarded-For $proxy_add_x_forwarded_for: This header appends the client's IP address to the X-Forwarded-For header, which may already contain a chain of IP addresses from previous proxies. This ensures a complete trace of the request’s origin, even through multiple proxy layers.
  • X-Forwarded-Proto $scheme: This header forwards the protocol used by the client to connect to the proxy (e.g., http or https). This is essential for the upstream server to generate correct URLs and handle protocol-specific logic.

This setup is commonly used to route traffic to backend services, handle WebSocket connections, and ensure that the upstream server receives the necessary information about the original request. Now, let’s see how we can achieve this in APISIX.

Translating Nginx Configuration to APISIX

So, how do we translate this Nginx configuration to APISIX? There are a couple of ways to do it. We can directly configure a route in APISIX that mimics the Nginx setup, or we can leverage APISIX plugins to achieve the same result. Let's explore both methods.

Method 1: Configuring a Route in APISIX

The most straightforward way is to create a route in APISIX that mirrors the Nginx configuration. This involves setting the appropriate upstream service, path, and headers. Here’s how you can do it:

  1. Define an Upstream: First, you need to define an upstream in APISIX that points to your backend service (http://localhost:3000). You can do this using the APISIX Admin API:
curl http://127.0.0.1:9180/apisix/admin/upstreams/1 -H 'X-API-KEY: YOUR_API_KEY' -X PUT -d '
{
